PERFECT’s industrial heavy-duty truck trailer can transport a large amount of material between the floor and the ramp, and overlap each other to create a large-capacity material handling train. The...
Introduction

PERFECT’s industrial heavy-duty truck trailer can transport a large amount of material between the floor and the ramp, and overlap each other to create a large-capacity material handling train. They are a key component of the “choose shopping cart” strategy, in which order pickers fill up the trailer with a large capacity, while the tug ships in batches to collect items in batches. These industrial heavy-duty truck trailers are very suitable for order picking applications and can be used as a supplement or even substitute for crane trucks. The manufacturing plant also uses Tugger trailers to move materials from one point on the production line to the next. Rather than carrying a single cargo at a time like a forklift, a train tractor-trailer allows the tractor operator to transport multiple cargoes in a single trip. The heavy-duty steel structure with a durable powder-coated surface makes the industrial Tugger trailer suitable for harsh industrial environments. Custom designs can be used for specific applications.



Parameters:

1 Body size: 4000*2500*500mm

2 Load: 3T, 5T

3 Body structure: Q235 channel steel main beam, the countertop is paved with national standard steel plate

4 wheels: 4 cast steel wheels for flatbed trailers,

5 Steering device: one-way traction turntable steering

6 traction: the folding rectangular tube traction frame can be adjusted up and down;

7 Surface treatment; smoothing, rust removal of the vehicle. Primer plus topcoat.



Application:

Commonly used in factories, railway stations, workshops, hauling materials, pallets, goods. Baggage handling at the station.
